CLV PLUS - CONCENTRIC - STAINLESS STEEL CHIMNEY SYSTEM

CLV+

The Schiedel CLV+ is a high-quality modular concentric flue system suitable for balanced exhaust gas discharge. It’s ideal for residential applications and allows multiple connections on each floor.

CONTACT & ADVICE

Highlights

The Schiedel CLV+ is a high-quality modular concentric flue system suitable for balanced exhaust gas discharge. Designed for multiple closed gas appliances under positive (up to 200 Pa) or negative pressure, it operates at a continuous temperature of up to 200°C. The lightweight stainless steel system features silicone sealing rings for positive pressure, ensuring tight connections. It’s ideal for residential applications and allows multiple connections on each floor. The system components include an inspection hatch for easy access and condensate drainage.

Tailormade solutions

Flexibility through customization: working with Schiedel allows you to access custom-made solutions for your CLV project. Tailor made parts, Diameter calculations, Implementation plans,... Our in-house engineering firm can help you with project management from A to Z!

Wide product range

The Schiedel CLV system stands out for its versatile product range, offering a wide array of connection options to suit various installation needs. Among its offerings are T-pieces with parallel 80/80, concentric 80/125, and 60/100 configurations, catering to different appliance requirements. This flexibility ensures that the system can be tailored to specific architectural designs, providing efficient and reliable exhaust solutions for modern gas appliances. The Schiedel CLV’s adaptability makes it a preferred choice for professionals seeking a comprehensive flue solution that accommodates a multitude of connection scenarios.

Efficient & scalable solution

Schiedel CLV has the ability to connect multiple boilers to the same diameter. Additionally the system can be equipped with inspection hatches for easy access during inspections and cleaning. This feature simplifies the installation process and reduces the need for multiple flue systems, saving both space and cost. It also ensures a uniform appearance and streamlines maintenance. With this capability, the Schiedel CLV system provides an efficient and scalable solution for residential and commercial buildings, making it an ideal choice for projects that require a centralized flue system accommodating several boilers. This innovative approach to flue design underscores Schiedel’s commitment to providing adaptable and practical solutions in the field of exhaust technology.

Details & Services

Find out more about the details and services for the CLV+ flue gas system, such as the structure, detailed technical data or suitable services. You also have the option of downloading flyers or brochures about the product.

Hover to zoom

The structure of the system

With Schiedel CLV+, multiple boilers can be connected to the same diameter. CLV+ system has a wide product range for multiple connection options, such as T-pieces with parallel (80/80), concentric (80/125, 60/100) connections.

The CLV+ system has great flexibility through customization as you can directly use Schiedel's Center of Engineering services for diameter calculations, implementation plans, etc. This way your CLV project is completely developed by Schiedel from A to Z.

Technical data

Basic data (dimensions, weight & co.)
Wall thickness per diameter (internal)	0,4 mm
Wall thickness per diameter (outside)	0,4 mm

Application
Flue gas temperature (dry)	≤ 200 °C
Material (Inner liner)	AISI 316L-EN 1.4404
Material (Outer case)	Material No.: 1.4301

General product features
Operating	Positive pressure (P-H), Negative pressure (N)
Room sealed	Yes
Occupation	Multi
Suitable for passive house	Yes
Heating technology	Condensing boiler technology, Low temperature technology
